A bigger screen. More possibilities.

From an idea to the first show.

Restaurants, hotels, retail spaces and stages. We select the display around viewing distance, lighting and content — not just its diagonal.

Configure your display Explore solutions

Concept illustration, not a photograph of a completed project

Part of the space. More than equipment.

Dimensions, brightness, construction and control should work together. We help define the requirements and develop a technical solution for your location.

Selection

Use case, viewing distance, content and installation conditions.

Design

Module layout, mounting, power and signal routes.

Installation

Assembly, connection and image setup.

Operation

Content control, training and maintenance planning.

Different needs. The right construction.

Start with the use case, then choose the technology.

Indoor installations

An image that works up close

Menus, presentations, brand content and live video. Prioritise close-range readability, comfortable brightness and service access.

Restaurants · hotels · meeting rooms

Configure your display

Indoor installations — Concept illustration, not a photograph of a completed project

Outdoor installations

Visible in daylight

For facades and entrances, account for sun, rain, temperature and the supporting structure. Connections need protection as well as the display.

Facades · entrances · outdoor venues

Configure your display

Outdoor installations — Concept illustration, not a photograph of a completed project

Stage and modular systems

For events and changing layouts: quick-assembly cabinets, mounting and live-video control.

Custom shapes

Curved surfaces, ribbons and unusual proportions. Geometry and service access need dedicated design.

How do you choose pixel pitch?

Pixel pitch is the distance between the centres of adjacent LED pixels. A smaller pitch fits more detail in the same area. The choice still depends on the viewer, content and actual screen resolution.

Close viewing

Small text and details need a denser image. Check readability at the intended distance.

Video and broadcasts

Match proportions and resolution to the source. A physically large screen is not necessarily 4K.

Distant audiences

Large graphics and short messages may not need the smallest pitch. Contrast and content scale matter.

Explore image perception with scale calibration and different viewing distances.

Compare pitches in the simulator

Select pitch by viewing distance

Compare pixel pitches for your audience. These are perception guidelines, not guarantees of image quality or module availability.

Pixel pitch, mmViewer distance, m

Indicative minimum

2.5 m

Comfort guideline

5–7.5 m

Dot blending (1 arcminute)

8.6 m

Distance exceeds the calculated dot-blending threshold.

Minimum ≈ pitch in mm → metres; comfort guideline ≈ 2–3×; dot blending ≈ 3.44×. Eyesight, content and brightness affect perception.

Indicative minimum	Comfort guideline	Dot blending (1 arcminute)
0.9 m	1.8–2.7 m	3.1 m
1.2 m	2.4–3.6 m	4.1 m
1.5 m	3–4.5 m	5.2 m
1.9 m	3.8–5.7 m	6.5 m
2.5 m	5–7.5 m	8.6 m
2.9 m	5.8–8.7 m	10 m
3.9 m	7.8–11.7 m	13.4 m
4.8 m	9.6–14.4 m	16.5 m
6 m	12–18 m	20.6 m
10 m	20–30 m	34.4 m
20 m	40–60 m	68.8 m

See the difference, not just the numbers

Choose a pitch, content and viewing distance. Each luminous dot represents one LED pixel. Smaller pitches produce a denser grid.

Approximate scale

Pixel pitch · mm

Content

Viewing distance

Custom distancem

0.1–200 m · 0.1 m increments

JPG, PNG or WebP · up to 8 MB and 16 MP · no animation. Converted to WebP. Available for 20 days; automatically deleted within 21 days. The original is not stored.

Anyone receiving your link or QR code can view this image. Do not upload documents, bank cards or confidential information.

1 dot = 1 LED pixel · P2.9From 10 m · Approximate scale

Grid spacing in the current render: 0.658 image px. Spacing is at or below one image pixel: the grid cannot be resolved, so different settings may look identical. This is a display limit, not a settings reset.

Minimum distance ≈

2.9 m

Comfortable viewing ≈

5.8–8.7 m

Angular resolution limit ≈

10 m

How to read the simulation

After calibration, the centre-to-centre spacing in 1:1 mode matches the selected pitch in millimetres. Before calibration, we assume an approximate density of 96 CSS pixels per inch.

The selected distance from 0.1 to 200 m adjusts the angular size of the grid relative to viewing your monitor from 60 cm. The image stays in place for comparison; this is not a scale model of a whole video wall.

This is an illustration, not a performance guarantee. Monitor density, eyesight, brightness, LED optics and content affect perception. Grids finer than the monitor resolution are smoothed. Compare real samples before selecting equipment.

Selection guidelines

Minimum distance: pitch in mm ≈ distance in m; comfortable viewing: about 2–3 times that distance. The theoretical resolution limit assumes one arcminute visual acuity and is not a required viewing distance.

Indoor or outdoor?

Consideration	Indoor	Outdoor
Lighting	Comfortable brightness for the room	Brightness suited to daylight
Protection	Indoor and cleaning conditions	Rain, dust, moisture and connections
Heat	Ventilation and visitor comfort	Sun exposure and heat removal
Service	Front or rear access	Safe facade and connection access

LED WALL CONFIGURATOR

LED wall configurator

Choose the environment, construction and desired dimensions. Geometry is calculated using whole modules or cabinets; prices are not calculated.

EnvironmentPitch and constructionSpecify size using

Desired width, mDesired height, m

Modules / panels · Assembly increment: 320 × 160 mm

Viewer distance, m

Indicative minimum: 2.5 m · Dot blending (1 arcminute): 8.594 m

Distance exceeds the calculated dot-blending threshold.

Start with a size

Preliminary geometry, not a design or complete equipment list. Power, weight, mounting, controller and module availability need separate confirmation.

Module-aligned dimensions

4.16 × 2.56 m

Layout and content preview

Show grid

4.16 m2.56 m

Person 1.75 m · Scale diagram. Content is cropped to the screen aspect ratio.

Assembly grid: 13 × 16 = 208
Diagonal: 4.885 m / 192.307″
Area: 10.65 m²
Resolution: 1664 × 1024 px
Modules: 13 × 16 = 208 pcs
Module size: 320 × 160 mm
Total pixels: 1,703,936

Let’s discuss your configuration

Your nameYour reply e-mail

Location, content and requirementsI consent to the use of my details to respond to this request.

The configuration will appear in the assistant input. Review it and send.

Compare pitches in the simulator

WLTT · LED

45 m² · P2.604 · 500×500 mm · 3456 × 1920 px

Selection and price on request

Open in configurator

Content where you need it

One large display or several display areas: define signal sources, schedules, live video and independent content first. Then select the controller and connection design.

From requirements to a working display

Not a fixed kit first: your objectives and site conditions first.

01
Selection
Use case, viewing distance, content and installation conditions.
02
Design
Module layout, mounting, power and signal routes.
03
Installation
Assembly, connection and image setup.
04
Operation
Content control, training and maintenance planning.

You have the space. Let’s find the solution.

Share dimensions, location and your content scenario through the form or discuss them with the AI assistant.
